Triumph Thunderbird User Manual

36
General Information
Seats
Seat Care
To prevent damage to the seats or seat
covers, care must be taken not to drop or
lean the seats against any surface which may
damage the seats or seat covers.
Rider Seat Removal
1. Seat fixing (right hand shown)
To remove the rider’s seat, remove the two
side fixings using the Allen key provided in
the tool kit. Lift the seat up at the back for
complete removal from the motorcycle.
To refit the seat, engage the seat’s tongue
under the fuel tank, fit and tighten the side
fixings to 9Nm.
T
Caution
To prevent damage to the seats or seat
covers, care must be taken not to drop the
seats. Do not lean the seats against the
motorcycle or any surface which may
damage the seats or seat covers. Instead,
place the seats, with the seat cover facing
upwards, on a clean, flat surface which is
covered with a soft cloth.
Do not place any item on the seats which
may cause damage or staining to the seat
covers.
Warning
To prevent detachment of the seat during
riding, after fitting always grasp the seat
and pull firmly upwards. If the seat is not
correctly secured it may detach from the
motorcycle. A loose or detached seat could
cause loss of motorcycle control and an
accident.
cfco
1

Triumph Thunderbird Specifications

General

Manufacturer	Triumph
Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Tubular steel, twin spine
Front Tyre	120/70 R19
Rear Tyre	200/50 R17
Seat Height	700 mm
Fuel System	Fuel injection
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm floating discs
Rear Brakes	Brembo 2-piston caliper
Fuel Tank Capacity	22 L
Power	97 hp (72 kW) @ 5900 rpm
