Triumph Thunderbird User Manual

35
General Information
Tool Kit and Handbook
1. Pillion seat
2. C-spanner
1. Allen key
The tool kit consists of an Allen key for
removal of the rider and pillion seats and a
C-spanner for adjustment of the rear
suspension. The Allen key is located behind
the left hand side panel (see page 34),
attached to a bracket. The C-spanner is
stored under the pillion seat, behind the
handbook.
To gain access to the handbook, remove the
pillion seat (see page 37). The handbook is
located on the underside of the pillion seat.
Note:
• The fitting of some accessory kits
requires removal of the original
pillion seat, which houses the
handbook. In these circumstances,
ensure the Owner's Handbook is
removed from the pillion seat and
carried with the motorcycle at all
times.
cfbm
2
1
cfbm
1

Triumph Thunderbird Specifications

General

Manufacturer	Triumph
Displacement	1699 cc
Bore x Stroke	107.1 mm x 94.3 mm
Compression Ratio	9.7:1
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Tubular steel, twin spine
Front Tyre	120/70 R19
Rear Tyre	200/50 R17
Seat Height	700 mm
Fuel System	Fuel injection
Final Drive	Belt
Front Suspension	Telescopic forks
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 310mm floating discs
Rear Brakes	Brembo 2-piston caliper
Fuel Tank Capacity	22 L
Power	97 hp (72 kW) @ 5900 rpm
