Ubee Interactive Using the CM Info Option
Ubee UBC1301-AA00 Advanced Wireless Voice Gateway Subscriber User Guide • March 2017 23
4.1.2 Using the Connection Option
The Connection screen displays information about the device’s connection status and
downstream and upstream channel bonding statistics.
 Downstream displays detailed information on the network traffic from the service
provider to the local computer (downstream channels).
 Upstream displays detailed information on the network traffic from the computer
to the remote destination (upstream channels).
Label Description
Information
Standard Specification
Compliant
Defines the current DOCSIS standard supported by the UBC1301-AA00.
Hardware Version Defines the internal version number that identifies the hardware design.
Software Version Defines the firmware version of the device.
Cable Modem MAC Address
Defines the unique media access control (MAC) hardware address of the
UBC1301-AA00.
Cable Modem Serial Number Defines the unique manufacturer serial number of the device.
CM certificate Indicates if the cable modem certificate is installed.
Status
System Up Time Displays how long the device has been connected.
Network Access
Defines if network access is enabled. When enabled, the user is allowed to
access the network.
Cable Modem IP Address Displays the IP address for the cable modem.
Board Temperature If available, displays the temperature of the board.
