Fig. 17 Overview
The function of the device status part is to display some specific information of the current device, including system, network, serial
port, mqtt gateway and Edge computing status.
Table 7 Overview status list
The name of the gateway, which can be customized by the user on the "Miscellaneous settings" page.
The current software version of the gateway.
The current hardware version of the gateway.
Total time after the device start work. It will starts from 0 after reboot.
The MAC address of the gateway.
Which interface to access the internet, default WAN interface, that is ethernet port.
The IP address of the gateway.
The working status of checked serial port. Select the serial port currently to be displayed
Conn Status A(ETH): connection status of socket A.
IDLE:Initialization status
LISTEN:When the module works as TCP Server, it is listening for connection access
CONNECTING:Works as TCP client, the module is establishing a connection to the TCP Server
CONNECTED:Works as TCP server, the TCP connection to TCP server of the module has been
established
CONNECTED（n）:Number of TCP clients connected to the module
ERROR:The module is abnormally disconnected
Tx Count A(ETH): To count how many bytes be send to internet.
Rx Count A(ETH): To count how many bytes received from internet.
Shows the connection status to the MQTT broker.
CONNECTING:the Smart I/O Controller is connecting to the MQTT broker
CONNECTED:the Smart I/O Controller is connected to an MQTT broker
ERROR:The module is abnormally disconnected due to invalid MQTT protocol version, invalid client ID,
unavailable broker, invalid client credentials or unknown reasons
Whether Edge computing is enable
Connection status of Edge computing.
CONNECTING:the module is establishing a socket or mqtt connection
CONNECTED:the socket or mqtt connection has been established
ERROR:The module is abnormally disconnected
3.1.2. IP settings
You must assign a valid IP address to the USR-M100 before it will work in your network environment. The IP address must be unique
within the network. If the device is connected to the Internet and should connect to other servers over the Internet to get some
