31
From the menu bar, select Database>New>Add. Then the following dialog box will pop
up.
2. Enter the required patient information. Chart number, first name and Last name are
required fields to be filled in.
3. Other fields, although optional, are recommended to be filled in.
4. Once all the necessary parameters are entered, Click Add to save configurations.
4.3 Turing on the PaX-Primo i
Before switching on the equipment, check that installation of the unit is complete.
To switch on the unit, follow these steps.
1. Press the ON/OFF switch on the column.
For the detailed operation on how to use this software, please refer to the
EasyDent user manual.
To increase the operating life of the X-Ray tube, if the equipment has not
been used for long time, you must pay special care before use.
