40
5.1.3 Preparing for launch of X-Ray
1. Click
There are two cases of environment, depending on availability of the storage devices at
the image-taking moment.
z USB or network connection not found
The following message will be displayed
You are given two choices. If Okayed it will proceed in a normal imaging steps
If canceled, it returns to the initial state.
z At least one is available
The following screen will appear
In summery the following flow chart explains the inter-working relationship between
modules from the “confirm “to “Ready” state.
To Next Page
