5 CBMS
5.1 CBMS description
BMS system consists of three levels of architecture. The cabinet-level management
system is Cabinet BMS, hereinafter referred to as CBMS. CBMS is responsible for
battery current detection, data collection and analysis, alarm and protection control,
communication with upper and lower levels, etc. CBMS consists of main circuit breaker,
charging and discharging double-loop control switch circuit, high-voltage isolation
detection circuit, parallel processing circuit, high-voltage power supply and DC starting
circuit, CBMS chassis and related wiring harness. State management and action protection
of over charge, over discharge, over current, short circuit can realize and ensure the safety
and reliability of the whole system.
5.2 CBMS specification
Table 5.2-1 CBMS spec
Item
50AH CBMS
100AH CBMS
Commercial Ref ID
LIBVISSG250TP0
LIBVISSG630TP0
Output configuration
2/3 wires
2/3wires
Rated Power: kw
93
186
Modules in configuration
8-14
8-12
Range of Voltage
(8-14)*51.2V
(8-12)*51.2V
Max discharging current
250A
500A
