9.4.3 Module detection before installed
Table 9.4-2 Modules parameters
Item
TP-10:51.2V50AH
TP-20:51.2V100AH
Commercial Ref ID
LIBVISMOD50
LIBVISMOD100
Resistance
7~9mΩ
4.5~6.5mΩ
Voltage
52.5~53.2V
52.5~53.2V
Table 9.4-3 Modules parameters
Item
TP-10:51.2V40AH
TP-20:51.2V200AH
Commercial Ref ID
LIBVISMOD40
LIBVISMOD200
Resistance
7~9mΩ
4.5~6.5mΩ
Voltage
52.5~53.2V
52.5~53.2V
Remarked: Live measurements can be done by only expert users
