Vision REVO User Manual

SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com
Green Our Earth Power Your Vision
82
10.6.7 AC power connection
The CBMS main control unit of REVO series system adopts DC and AC double safety power
supply mode. When the mains power is normal, the mains power will be supplied by AC first. The
specification is 85~264VAC (±5% variation range), and the frequency is 47~63Hz.
AC connection source can be from UPS output or other mains AC. (Only expert users can connect
UPS output and AC source)
Figure 10.6-26 AC cable specifications
Only expert users could make a plug and connect the power source to the CBMS)
Figure 10.6-27 CBMS parallels AC power connection
