SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com
Green Our Earth Power Your Vision
Figure 10.2-2 Ground(PE) connect
10.3 Module installation
Install the main control CBMS and the battery modules from bottom to top on the specified
cabinet, and fix modules on the cabinet with cross head bolts with screw bolts provided with 7 Nm,
as shown below
Pay attention to the weight of the module during transportation.
This operation must be carried out by at least two skilled users
To Next Page
