8 Communication
8.1 Communication with UPS
REVO series Li-ion battery system communicates with UPS through the top integrated
GBMS, which transfers all the working status of lithium battery (overcharge, discharge,
over current, short circuit, over temperature, etc.) to UPS. According to the alarm or
protection status of lithium battery system, UPS ensures the safety of the whole working
system. Such communication is through CAN and RS485. RS485 protocol supports the
MODBUS RTU MODBUS/TCP protocol. The communication signals of REVO lithium
battery system are as follows:
Figure 8.1-1 Communication ports
