10.7 UPS Parameter Setting
Item
Description
Value
Remarked
2
Battery Block per string
40
50/100/40/200 AH Lithium Module No is 10
4
Battery block capacity
50/100/40/200Ah
Depends on the batteries cabinet
5
Recommended charging current
0.2C-0.5C
50AH cabinet:10A-25A
100AH cabinet :20-50A
40AH cabinet:8A-20A
200AH cabinet:40A-100A
6
Float Voltage(V)
54*n
n=Lithium batteries module Qty in cabinets
7
Boost Voltage(V)
54.4(55.2)*n
n=Lithium batteries module Qty in cabinets
8
EOD Voltage(V)
44.8*n
n=Lithium batteries module Qty in cabinets
11 Running Test
11.1 Starting up examination
11.1.1 START-UP CHECKLIST
 Obtain a copy of the customer sales order number being worked.
 Verify with the sales order that the correct units were shipped.
o Check the CBMS & with System GBMS
o Check the CBMS & without System GBMS
 Inventory the shipment to ensure all parts were shipped and there is no shipping damage or part
shortages.
 Before installing into the cabinet, check the insulation resistance of the battery module.
Note: Refer to Insulation Resistance Test Manual.
 Install all components (CBMS, battery modules, GBMS, Cabinet,communication cables, etc.).
