Air Inlet and Exhaust Systems
Air fi lter change
Check the air fi lter indicator. If indicator is all red after
the engine is stopped, change fi lter.
1. Undo the clamps and remove the lid from the fi l-
ter housing.
2. Remove the old fi lter. Be careful to ensure that no
contamination gets into the engine.
3. Install a new air fi lter and tighten the lid.
4. Reinstate the pressure drop indicator by pressing
in the indicator button.
IMPORTANT! Scrap the old fi lter. It must not be
cleaned.
Inlet drain hole
Water can condense in the charge air cooler during
operation. The condensate is drained via a hose
connected to a nipple mounted after the charge air
cooler.
Check that the nipple is not blocked.
WARNING! If a large amount of water fl ows out
of the drain hole, the charge air cooler must be
removed and proof tested. This must be done by
an authorised workshop.
67
Maintenance: Air Inlet and Exhaust system
