6.3 Technical Data
Dimensions
Height
175 mm
Length
245 mm
Weight
without printing materials
2.0 kg
Power supply voltage
Input
100 VAC … 240 VAC maximum 1.6 A
50 Hz … 60 Hz
Output
24 VDC … 2.5 A
Power
Interfaces
USB 2.0
Serial RS–232 (DB-9)
ETHERNET
USB host
Ambient temperature
during operation
+5 °C… 40 °C (+41 °F … +104 °F)
during transport/storage
−20 °C… 50 °C (−4 °F … 122 °F)
Ambient humidity
during operation
30 % to 85 %, relative humidity, non-condensing
during transport/storage
10 % to 90 %, relative humidity, non-condensing
Storage
Flash
8 MB
4 MB for applications
SDRAM
16 MB
Printing mode
Thermal transfer, Thermodirect
Resolution
300 dpi x 300 dpi (12 pixels/mm x 12 pixels/mm)
Print speed (max.)
127 mm/s (5 in/s)
Print width
56.9 mm (2.24″)
Print length
minimum 4 mm (0.16″) / maximum 762 mm (30.0″)
Sensor
Type
Transmissive sensor
Position
adjustable
Print material
detection
Label gap, black mark, continuous material
Width
minimum 15 mm (0.6″) / maximum 60 mm (2.36″)
Thickness
minimum 0.06 mm (0.003″) … maximum 0.20 mm (0.008″)
Roll diameter
maximum 127 mm (5″)
Internal core diameter
25.4 mm (1″), 38.1 mm (1.5″)
Ink ribbon
Quality
Resin
Length
74 m
Width
50 mm
External core diameter
maximum 38 mm (1.5″)
Internal core diameter
12.7 mm
Printer language
EZPL, GEPL, GZPL, automatic setting
Software
Label software
Drivers
Windows 2000, XP, 7, 8, 10, Windows Server 2003 & 2008
DLL
Windows 2000, XP and 7, 8, 10
Internal fonts
Bitmap fonts
6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
90°, 180°, 270° rotatable
individual characters rotatable by 90°, 180°, 270°
horizontally and vertically scalable by a factor of eight
Scalable fonts
90°, 180°, 270° rotatable
Loadable fonts
Bitmap fonts
90°, 180°, 270° rotatable
individual characters rotatable by 90°, 180°, 270°
Asian fonts
90°, 180°, 270° rotatable
horizontally and vertically scalable by a factor of eight
Scalable fonts
90°, 180°, 270° rotatable
