2 Freedom SW Owner’s Guide
Introduction
Materials List
The Freedom SW ships with the following items:
• One Freedom SW unit
• Owner’s and Installation Guides
• Battery Temperature Sensor (BTS)
• DC terminal covers (one red, one black) with
two sets of #6-32 screws
• Two Xanbus network terminators
• Two sets of 5/16”-18 nuts and washers for the DC
terminals
NOTE: If any of the items are missing, contact customer
service or any authorized Xantrex dealer for replacement. See
“About This Guide” on page ii.
IMPORTANT:
Keep the carton and packing material in case you need
to return the Freedom SW for servicing.
Figure 1 Materials List
FREEDOM SW
3012
FREEDOM
SW
3012
CLEAR FAULT
RESET
INVERTER
ENABLE
INVERTER
ENABLED
AC IN
FAULT
GEN
SUPPORT
CHARGING
WARNING
BTS
DC terminal covers
with screws
nuts and washers
Freedom SW 3012 shown
Installation and
Owner’s Guides
Xanbus network
terminators
FSW Owners Guide.book Page 2 Tuesday, August 7, 2018 9:03 AM
