64 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
ACIn Settings
The ACIn Settings menu configures the voltage and
frequency limits for AC Input quantification range. These are
the limits at which the Freedom SW considers input voltage
qualified—that is, suitable for charging batteries or powering
loads. If the input voltage is not qualified according to these
settings, the Freedom SW transfers from using AC input to
inverting.
Figure 30 ACIn Settings Menu Screen
Table 14 Setting Defaults and Ranges
Model Freedom SW 2012 / 3012 Freedom SW 2024 / 3024
Item Default Min Max Default Min Max
AC1 Breaker 30A 5A 30A 30A 5A 30A
AC1 Lo Volt 95V 78V 115V 95V 78V 115V
AC1 Hi Volt 135V 125V 140V 135V 125V 140V
AC1 Lo Freq 55Hz 44Hz 59Hz 55Hz 44Hz 59Hz
AC1 Hi Freq 65Hz 61Hz 70Hz 65Hz 61Hz 70Hz
FSW3012 00: ACIn Settings
ACIn Breaker
ACIn Lo Volt
ACIn Hi Volt
ACIn Lo Freq
ACIn Hi Freq
[30A]
[95V]
[135V]
[55Hz]
[65Hz]
Follow procedures on “To select and change a
configurable setting:” on page 43 to change the settings.
FSW Owners Guide.book Page 64 Tuesday, August 7, 2018 9:03 AM
