48 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
Changing Freedom SW Basic Settings
Basic Settings menu The Freedom SW configuration
settings can be viewed in basic format (see “Selecting Basic
Settings From the Device Setup Screen” on page 48). The
basic settings include configuration items you may have to
adjust routinely, or as part of initial setup. It provides access
to basic control of the inverter/charger.
To select the Basic Settings menu screen:
1. On the FSW3012 00:Setup screen (Figure 22), press the
Down arrow button until Basic Settings is
highlighted.
2. Then, press Enter to display the FSW3012 00: Basic
screen which is the basic settings menu screen.
3. Press the Up and Down arrow buttons to move between
selectable fields.
The Freedom SW basic settings include menus for
configuring:
• Battery type
• Battery capacity
• Maximum charging rate
• Charging cycle
• Recharging volts
• AC In breaker rating
• Low battery cutout value
See Table 7, “Basic Settings” on page 50 for information on
each setting.
Figure 22 Selecting Basic Settings From the Device Setup Screen
FSW3012 00: Setup
Desired Mode
Clear Faults Warnings
View Device Info
Basic Settings
[Standby]
FSW Owners Guide.book Page 48 Tuesday, August 7, 2018 9:03 AM
