56 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
Inverter Settings Menu
The Inverter Settings menu contains settings that control
when the Freedom SW starts and stops producing AC output.
Figure 27 Inverter Settings Menu Screen
Table 8 Setting Defaults and Ranges
Model Freedom SW 2012 / 3012 Freedom SW 2024 / 3024
Item Default Min Max Default Min Max
Low Batt Cut Out 10.5V 10.0V 12.0V 21.0V 20.0V 24.0V
LBCO Delay 10sec 0sec 600sec 10sec 0sec 600sec
Hi Batt Cut Out 16.5V 14.5V 17.0V 33.0V 29.0V 15.5V
Search Watts 50W 25W 250W 50W 25W 250W
Search Delay 2sec 1sec 25sec 2sec 1sec 25sec
FSW3012 00: Inv Settings
Low Batt Cut Out
LBCO Delay
Hi Batt Cut Out
Search Watts
Search Delay
[11.0]
[10sec]
[15.5V]
[50W]
[2sec]
Follow procedures on “To select and change a
configurable setting:” on page 43 to change the settings.
Table 9 Inverter Settings Description
Item Description
Low Batt
Cut Out
Low Battery Cut Out (LBCO) controls when the
inverter stops producing AC output due to a low
battery voltage condition. The inverter will stop
producing AC output only after this level has
been reached for the period of time set by the
LBCO Delay. This setting is not temperature
compensated.
LBCO Delay LBCO Delay controls how long the inverter is
allowed to operate at or below the
Low Batt Cut Out level before turning off due
to a low battery voltage condition. The inverter
will stop producing AC output only after the Low
Batt Cut Out level has been reached for this
uninterrupted period of time.
Once the inverter has shut off, the battery voltage
must rise 2 volts above the Low Batt Cut Out
setting (4 volts for 24-volt systems) for inverter
operation to resume.
FSW Owners Guide.book Page 56 Tuesday, August 7, 2018 9:03 AM
