97-0019-01-01 63
Configuring the Freedom SW using the SCP
Table 13 describes the items on the Custom Battery
Settings menu.
Table 13 Custom Battery Settings Menu Description
Item Description
Eqlz
Support
Enables or disables the ability to enter an
equalization cycle. Refer to the battery
manufacturer’s specifications to determine whether
equalization is recommended.
Eqlz
Voltage
a
Selects the equalization voltage. Consult your
battery manufacturer for equalization voltage
setting.
Bulk
Voltage
Sets the bulk voltage for a custom battery type. This
setting must be 0.4 V (or 0.2) or higher than Bulk
Termination Voltage for the 24-volt model (or 12-
volt model). See note below.
BulkTerm
ination
Voltage
Sets the bulk termination voltage for a custom
battery type. This setting must be 0.4 V (or 0.2) or
lesser than Bulk Voltage for the 24-volt model (or
12-volt model). See note below.
Absorb
Voltage
Sets the absorption voltage for a custom battery
type.
Float
Voltage
Sets the float voltage for a custom battery type. See
note below.
Batt
Temp
Comp
Battery temperature compensation for a custom
battery type. This setting is the reference that the
BTS uses to adjust the charging voltage when the
temperature is above or below 25 °C (77 °F).
a. The Eqlz Voltage setting is displayed when Eqlz Support is set to On.
NOTE: If a warning is received indicating that a setting is not accepted
by the SCP, gradually increase the value of the setting until the SCP
accepts it. This type of warning means that an internal minimum threshold
value is being crossed and therefore the setting cannot be saved.
Table 13 Custom Battery Settings Menu Description
Item Description
FSW Owners Guide.book Page 63 Tuesday, August 7, 2018 9:03 AM
