66 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
Gen Support
GEN Support is basically generator (and also shore power)
support for the Freedom SW that allows power to be
automatically drawn from the batteries to assist an AC
generator or shore power to support heavy loads (for example,
loads that exceed the available current from either a generator
or shore power).
Generators and shore power have a limited output current and
it is possible to reach this limit when operating heavy loads.
When heavy current demand from the load is needed,
additional power from the batteries can supply the needed
energy.
In addition, the battery charger can reduce its charging current
to the batteries so the combined charge AC current and total
load current do not exceed the capacity of the generator (and
shore power) or trip its output breakers or fuses.
Figure 31 GEN Support Menu Screen
NOTE: Running and start-up (peak) currents are limited to the maximum
current limits of the inverter.
Table 16 GEN Support Menu Description and Values
a
Setting Description Default Range
GenSup
Mode
Turns the generator
or shore power
support feature on
and off.
Disabled Disabled,
Enabled
FSW3012 00: GEN Support
GenSup Mode
GenSup Amps
[Disabled]
[30A]
[*Disabled] [Enabled]
Follow procedures on “To select and change a
configurable setting:” on page 43 to change the settings.
FSW Owners Guide.book Page 66 Tuesday, August 7, 2018 9:03 AM
