62 Freedom SW Owner’s Guide
Configuring the Freedom SW using the SCP
Custom Battery Settings Menu
The Custom Battery Settings menu can be viewed if
Custom is selected as the Batt Type. This menu allows you
to adjust charging and equalization voltage for batteries with
specifications that fall outside the default settings for the
battery types the Freedom SW offers. You can also adjust the
temperature compensation constant for the battery
temperature sensor on this menu.
EQUIPMENT DAMAGE
Consult your battery manufacturer and associated documentation before
setting a custom battery type to avoid damaging your batteries during
charging or equalization.
Failure to follow these instructions can damage the unit and/or damage
other equipment.
Figure 29 Custom Settings Menu Screen
FSW3012 00: Cust Settings
Eqiz Support
Eqiz Voltage
Bulk Voltage
Bulk Termination Voltage
Absorb Voltage
Float Voltage
BattTempComp
[Enabled]
[16.0V]
[11.2V]
[11.0V]
[13.5V]
[-27mV/K]
Appears only when
Equalize support is Enabled.
Follow procedures on “To select and change a
configurable setting:” on page 43 to change the settings.
Table 12 Setting Defaults and Ranges
Model Freedom SW 2012 / 3012 Freedom SW 2024 / 3024
Item Default Min Max Default Min Max
Eqlz Support Enabled Enabled,
Disabled
Enabled Enabled,
Disabled
Eqlz Voltage 15.5V 13.5V 16.0V 31.0V 27.0V 32.0V
Bulk Voltage 14.4V 11.2V 16.0V 28.8V 22.4V 32.0V
Bulk
Termination
Voltage
14.2V 11.0V 15.8V
28.4V 22.0V 31.6V
Absorb Voltage 14.4V 12.0V 16.0V 28.8V 24.0V 32.0V
Float Voltage 13.5V 11.0V 16.0V 27.0V 22.0V 32.0V
Batt Temp Comp 27-mV 0-mV 45-mV 54-mV 0-mV 90-mV
IMPORTANT: All settings for configuring a custom battery type are based
on the default settings for a flooded battery type.
FSW Owners Guide.book Page 62 Tuesday, August 7, 2018 9:03 AM
