XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction 28
Quick Start for Plot Nesting (continued)
Setting Plot Nesting Parameters
The Miscellaneous Page contains a Plot Nesting Table enabling you to set
the following Plot Nesting parameters:
Enabled — Click on this check box to enable/disable the nesting of plots
from one or more print jobs. A check mark within the box means that Plot
Nesting has been enabled. The factory default setting is Off.
Exclusive — Click on this check box to enable/disable a plot nest restricted
to the contents of one specific job source. The factory default setting is Off.
Timeout — In this text box, enter the maximum idle time (in seconds) for the
printer to wait after processing a print job, before printing and cutting a nested
page. The factory default is 5 seconds.
Margins — In this text box, enter the printer-imposed margin spacing
between plots on a nested page. The factory default is zero (0).
Nesting Length — Enter the maximum length of a plot to be included in the
printed nest. If a plot exceeds this length, the nest will be terminated and the
plot will be printed separately. The factory default is 60.96 cm.
Press the Update Printer button to update the Miscellaneous parameters in
the Controller. The Controller will send back a message stating whether or
not the changes were made.
To Next Page
