XES Synergix 8825/8830/8850/8855 & X2-TECH System Introduction 68
Appendix 4 - XES Synergix 8825/8830/8850 Printer/Digital Solution Features and
Specifications
Printer Feature Description/Specifications
8825 - EV4 Controller Specifications
Hardware Specifications
CPU: Power PC 8240 (603e) operating at 250 MHz clock speed.
RAM: 64MB DRAM is standard. Maximum RAM is 256MB. Two DIMM Slots accommodate 64 or 128MB, PC100, DIMMs.
Hard disk: Ultra SCSI, 7200 rpm internal hard disk drive.
Physical Characteristics
The Controller is attached to the side panel of the 8825 Printer as an embedded device.
Electrical Requirements
100 - 250 VAC auto-ranging power supply
Agency Approvals
Safety: UL 1950, CA22.2 No. 950 (CUL), EN 60950 (CE Mark)
EMC: CE Mark, FCC Class A, Canada Radio Interference Regulations Class A, VCCI Class 1
I/O Ports
Serial Two 9 pin Host serial ports provided. One is used by the 8825 Digital Solution scanner when this option is connected. The second is
used as an input port for receiving data via serial port connection.
Parallel (IEEE 1284 Compliant) High density port connector provided.
SCSI Optional 50 pin SCSI-2 card available.
VPI Optional card available.
TCP/IP 10/100 Ethernet Network Interface Port provided: RJ-45 connection, supporting TCP/IP only.
Network Optional External Ethernet Adapter available to support TCP/IP, Novell 3.x, 4.x, 5.x, and NetBEUI.
IEEE 1394 Interface supporting the Synergix Scan System
