Page 110 FT-2000D OPERATING MANUAL
MISCELLANEOUS AFSK-BASED DATA MODES
The FT-2000D may also be used for a host of other SSB-based Data modes. Please set up your system using the illustration
as a guideline.
QUICK POINT:
When you have configured Menu item “148 tGEn VOX
SEL” to “
dAtAdAtA
dAtAdAtA
dAtA,” the transceiver will operate in a “VOX”
mode, and it is not necessary to connect a PTT line. This
makes for very convenient interfacing to computer Sound
Cards, etc.
①
⑤④
③
②
PACKET
Interface
DATA OUT
GND
PACKET PTT
DATA IN
LINE IN or MIC IN
LINE OUT or MIC OUT
COM PORT
Interface
PACKET JACK
Pin 1
(
DATA IN
)
Pin 2
Pin 3
Pin 4
Pin 5
(
GND
)
(
PACKET PTT
)
(
DATA OUT
)
(
BUSY
)
To Next Page
