Yamaha F150A - Page 222

6-45
Vapor separator and high-pressure fuel pump
9. Install a new gasket “1”, the filter holder
“2”, and the cover “3”, and then tighten
the float chamber cover screws “4” to the
specified torque.
10. Install the pressure regulator “1”, and
then tighten the pressure regulator screw
“2” to the specified torque.
Float chamber cover screw “4”:
2 N·m (0.2 kgf·m, 1.5 ft·lb)
Pressure regulator screw “2”:
5 N·m (0.5 kgf·m, 3.7 ft·lb)
3
1
2
a
a
2
3
1
4
2
1
