Yamaha FZ1 - Right View

DESCRIPTION
2-2
2
Right view
13. Owner’s tool kit (page 6-1)
14. Rear brake fluid reservoir (page 6-30)
15. Battery (page 6-37)
16. Front brake fluid reservoir (page 6-29)
17. Radiator cap (page 6-17)
18. Engine oil filter cartridge (page 6-13)
19. Engine oil level check window (page 6-12)
20. Brake pedal (page 3-8)
21. Coolant reservoir (page 6-15)
