Yamaha FZ1 User Manual

INSTRUMENT AND CONTROL FUNCTIONS
3
Main switch/steering lock .................................................................. 3-1
Indicator and warning lights ............................................................. 3-2
Speedometer unit .............................................................................. 3-3
Tachometer unit ................................................................................. 3-4
Self-diagnosis devices ....................................................................... 3-5
Fuel gauge ........................................................................................ 3-5
Handlebar switches ........................................................................... 3-6
Clutch lever ....................................................................................... 3-7
Shift pedal ......................................................................................... 3-7
Brake lever ........................................................................................ 3-7
Brake pedal ....................................................................................... 3-8
Fuel tank cap ..................................................................................... 3-8
Fuel ................................................................................................... 3-9
Starter (choke) lever ........................................................................ 3-10
Seat ................................................................................................. 3-11
Helmet holder .................................................................................. 3-11
Storage compartment ..................................................................... 3-12
Adjusting the front fork .................................................................... 3-12
Adjusting the shock absorber assembly .......................................... 3-14
EXUP system .................................................................................. 3-17
Sidestand ........................................................................................ 3-17
Ignition circuit cut-off system ........................................................... 3-18
U5LV12.book Page 1 Thursday, June 27, 2002 5:49 PM

Yamaha FZ1 Specifications

General

Displacement	998cc
Bore x Stroke	77.0 mm x 53.6 mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel Injection
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70-ZR17
Rear Tire	190/50-ZR17
Engine Type	Liquid-cooled, 4-stroke, DOHC, inline 4-cylinder
Ignition	TCI
Front Suspension	43mm inverted fork, fully adjustable
Rear Suspension	Single shock, adjustable preload and rebound damping
Front Brakes	Dual 320mm disc
Rear Brakes	245mm disc
Wheelbase	1, 460 mm (57.5 in)
Seat Height	815 mm (32.1 in)
Fuel Capacity	18 liters (4.8 gallons)
Curb Weight	487 lb
Torque	106 Nm (78.2 ft lbs) @ 8, 000 rpm
Length	2, 140 mm (84.3 in)
Width	770 mm (30.3 in)
Ground Clearance	135mm (5.3 inches)
Wet Weight	487 lb
