PERIODIC MAINTENANCE AND MINOR REPAIR
6-8
6
EAU01122
Removing and installing
panels
The panels shown above need to be
removed to perform some of the main-
tenance jobs described in this chapter.
Refer to this section each time a panel
needs to be removed and installed.
EAU04003
Panels A and C
To remove one of the panels
Remove the screw, and then pull the
panel off as shown.
1. Panel A
2. Panel B
1. Panel C 1. Panel A
2. Screw
