Yamaha FZ1 User Manual

OPERATION AND IMPORTANT RIDING POINTS
5-6
5
EAU03749*
0–1,000 km (0–600 mi)
Avoid prolonged operation above
5,000 r/min.
1,000–1,600 km (600–1,000 mi)
Avoid prolonged operation above
6,000 r/min.
EC000052*
CAUTION:
_
After 1,000 km (600 mi) of operation,
the engine oil must be changed and
the oil filter cartridge replaced.
_
1,600 km (1,000 mi) and beyond
The vehicle can now be operated
normally.
EC000053
CAUTION:
_
●
Keep the engine speed out of
the tachometer red zone.
●
If any engine trouble should oc-
cur during the engine break-in
period, immediately have a
Yamaha dealer check the vehicle.
_
EAU00460
Parking
When parking, stop the engine, and
then remove the key from the main
switch.
EW000058
WARNING
_
●
Since the engine and exhaust
system can become very hot,
park in a place where pedestri-
ans or children are not likely to
touch them.
●
Do not park on a slope or on
soft ground, otherwise the
motorcycle may overturn.
_
U5LV12.book Page 6 Thursday, June 27, 2002 5:49 PM

Yamaha FZ1 Specifications

General

Displacement	998cc
Bore x Stroke	77.0 mm x 53.6 mm
Compression Ratio	11.5:1
Fuel Delivery	Fuel Injection
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70-ZR17
Rear Tire	190/50-ZR17
Engine Type	Liquid-cooled, 4-stroke, DOHC, inline 4-cylinder
Ignition	TCI
Front Suspension	43mm inverted fork, fully adjustable
Rear Suspension	Single shock, adjustable preload and rebound damping
Front Brakes	Dual 320mm disc
Rear Brakes	245mm disc
Wheelbase	1, 460 mm (57.5 in)
Seat Height	815 mm (32.1 in)
Fuel Capacity	18 liters (4.8 gallons)
Curb Weight	487 lb
Torque	106 Nm (78.2 ft lbs) @ 8, 000 rpm
Length	2, 140 mm (84.3 in)
Width	770 mm (30.3 in)
Ground Clearance	135mm (5.3 inches)
Wet Weight	487 lb
