Yealink SIP-T29G User Manual

User Guide for the SIP-T29G IP Phone
114
Live Dialpad
You can enable live dialpad on the SIP-T29G IP phone, which enables the IP phone to
automatically dial out a phone number without pressing the send key. You can also configure a
delay, and then the phone will dial out the phone number automatically after the designated
period of time.
To enable the live dialpad via web user interface:
1. Click on Settings->Preference.
2. Select Enabled from the pull-down list of Live Dialpad.
3. Enter the desired delay time in the Inter Digit Time(1~14s) field.
The default delay time is 4s.
4. Click Confirm to accept the change.
Note
Hotline
You can dial a hotline number immediately upon lifting the handset, pressing the Speakerphone
key or the line key. You can also configure a delay, and then the phone will dial out the hotline
number automatically after the designated period of time.
To configure the hotline number via phone user interface:
1. Press Menu->Features->Others->Hot Line.
2. Enter the desired number in the Hotline Number field.
3. Enter the delay time in the Hotline Delay field.
Live dialpad is configurable via web user interface only.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
