Yealink SIP-T29G User Manual

Advanced Phone Features
193
Shared Call Appearance (SCA)
You can use SCA feature to share an extension which can be registered on two or more IP
phones at the same time. The shared line is indicated by a different line icon.
In the following figure, the first line is private and the second line is shared:
If two phones share a line, an incoming call to this extension will cause both phones to ring
simultaneously. The incoming call can be answered on either phone but not both.
This feature is very useful in the boss and secretary scenario. For example, the secretary can
share the boss's extension on her phone. When there is an incoming call to the extension of the
boss, both the phones of the boss and the secretary will ring simultaneously. Either the boss or
the secretary can answer the call. Calls on the shared line can be placed on hold, barged in or
retrieved from another shared phone.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
