Yealink SIP-T29G User Manual

Customizing Your Phone
49
To configure the backlight via phone user interface:
1. Press Menu->Basic->Display->Backlight.
2. Press or , or the Switch soft key to select the desired value from the Active Level
field.
3. Press or , or the Switch soft key to select the desired value from the Inactive
Level field.
4. Press or , or the Switch soft key to select the desired time from the Backlight
Time field.
5. Press the Save soft key to accept the change or the Back soft key to cancel.
Backlight is configurable via web user interface at the path Settings->Preference.
Contrast
You can only configure the contrast of EXP20 connected to the SIP-T29G IP phone to a
comfortable level. Ensure EXP20 has been connected to the phone before configuration. The
intensity of contrast ranges from 1 to 10 and the highest intensity is 10.
To configure the contrast via phone user interface:
1. Press Menu->Basic->Display->Contrast.
If EXP20 is not connected to the phone, the Contrast Setting screen displays "No EXP".
2. Press or , or the Switch soft key to increase or decrease the intensity of contrast.
The default contrast level is “6”.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
