Yealink SIP-T29G User Manual

User Guide for the SIP-T29G IP Phone
158
To pick up a call in the group:
1. Pick up the handset, press the Speakerphone key or press the line key.
The GPickup soft key appears on the LCD screen.
2. Press the GPickup soft key on your phone when a phone in the group receives an incoming
call.
The call is answered on your phone.
You can also configure a DSS key as a group pickup key via phone user interface or web user
interface. Once configured, you can pick up a call by pressing the group pickup key directly. For
more information, refer to DSS Keys on page 91.
Note
Anonymous Call
You can use anonymous call to block your identify and phone number from appearing to the
called party when you call someone. For example, you want to call to consult some of the
services, but don’t want to be harassed. Anonymous call is configurable on a per-line basis. You
can also configure the phone to send anonymous code to the server to activate/deactivate
anonymous call on the server side.
Note
To configure anonymous call via phone user interface:
1. Press Menu->Features->Anonymous.
2. Select the desired line and then press the Enter soft key.
3. Press or , or the Switch soft key to select Enabled from the Local Anonymous
field.
Anonymous call is not available on all servers. Contact your system administrator for the
anonymous call on code and off code.
The directed call pickup code and group call pickup code are predefined on the system server.
Contact your system administrator for more information.
The call pickup code configured on a per-line basis takes precedence over that configured on a
global basis.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
