Yealink SIP-T29G User Manual

Basic Call Features
149
This feature allows you to perform the following:
 Join two calls together into a conference call.
 Invite another party into an active conference call.
To use this feature, contact your system administrator for the network conference URI in
advance.
To configure network conference via web user interface:
1. Click on Account->Advanced.
2. Select the desired account from the pull-down list of Account.
3. Select Network Conference from the pull-down list of Conference Type.
4. Enter the conference URI (e.g., conference@example.com) in the Conference URI field.
5. Click Confirm to accept the change.
Note
To set up a network conference call:
1. Place a call to the first party.
2. Press or the Conference soft key to place a new call.
The active call is placed on hold.
3. Enter the number of the second party and then press , , or the Send soft key.
4. When the second party answers the call, press or the Conference soft key to add the
second party to the conference.
5. Press or the Conference soft key to place a new call.
Network conference is configurable via web user interface only.

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
