Yealink SIP-T46G User Manual

Advanced Phone Features
189
The sender’s phone places the multicast RTP session on hold and receiver’s phone
releases the session.
To resume the held multicast RTP session, press the Resume soft key.
The multicast RTP session is established again.
 To end the multicast RTP session, press the End Call soft key.
Note
To send RTP stream via a paging list key when the receiver’s phone is idle:
1. Press the paging list key when the phone is idle.
2. Press or to select the desired paging group.
3. Press or the Paging soft key to send RTP.
4. Your can do the following:
 To place the current multicast RTP session on hold, press the Hold soft key.
The sender’s phone places the multicast RTP session on hold and receiver’s phone
releases the session.
To resume the held multicast RTP session, press the Resume soft key.
The multicast RTP session is established again.
 To end the multicast RTP session, press the End Call soft key.
Music on Hold (MoH)
Music on hold (MoH) is the business practice of playing recorded music to fill the silence that
would be heard by the party placed on hold. To use this feature, you should specify a SIP URI
pointing to a Music on Hold Server account. When a call is placed on hold, the phone will send a
SIP INVITE message to the Music on Hold Server account. The Music on Hold Server account
automatically answers the SIP INVITE messages and immediately plays audio from some source
located anywhere (LAN, Internet) to the held party. Contact your system administrator for the
SIP URI.
Note
To configure music on hold server via web user interface:
1. Click on Account->Advanced.
2. Select the desired account from the pull-down list of Account.
Multicast RTP is one way only from the sender to the multicast address(es) (receiver). For
outgoing RTP multicasts, all other existing calls on the phone will be placed on hold.
If your server supports the MOH feature, you can also upload the custom music file into it
directly. For more information, contact your service provider.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
