Yealink SIP-T46G User Manual

User Guide for the SIP-T46G IP Phone
78
To configure incoming/outgoing call lookup and update time interval via web user
interface:
1. Click on Directory->Remote Phone Book.
2. Select Enabled from the pull-down list of Incoming/Outgoing Call Lookup.
3. Enter the desired refresh period in the Update Time Interval(Seconds) field.
The default value is 21600.
4. Click Confirm to accept the change.
Call History Management
The SIP-T46G IP phone maintains call history lists of Missed Calls, Placed Calls, Received Calls
and Forwarded Calls. Each call history list supports up to 100 entries. You can view call history,
place a call, add a contact or delete an entry from the call history list.
History record feature is enabled by default. If you don’t want to save the call history, you can
disable the feature.
Viewing History Records
To view call history:
1. Press the History soft key.
The LCD screen displays all call records.
2. Press or to switch among All Calls, Missed Calls, Placed Calls, Received Calls
and Forwarded Calls.
3. Press or to select the desired entry.
4. Press the Option soft key, and then select Detail from the prompt list.
The detailed information of the entry appears on the LCD screen.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
