Yealink SIP-T46G User Manual

User Guide for the SIP-T46G IP Phone
48
Level field.
4. Press or , or the Switch soft key to select the desired time from the Backlight
Time field.
5. Press the Save soft key to accept the change or the Back soft key to cancel.
Backlight is configurable via web user interface at the path Settings->Preference.
Contrast
You can only configure the contrast of the expansion module EXP40 connected to the SIP-T46G
IP phone to a comfortable level on the phone. Ensure that the expansion module has been
connected to the phone before configuration. The intensity of contrast ranges from 1 to 10 and
the highest intensity is 10.
To configure the contrast via phone user interface:
1. Press Menu->Basic->Display->Contrast.
If EXP40 is not connected to the phone, the Contrast screen displays "No EXP".
2. Press or , or the Switch soft key to increase or decrease the intensity of contrast.
The default contrast level is “6”.
3. Press the Save soft key to accept the change or the Back soft key to cancel.
Language
The default language of the phone user interface is English. If the language of your web browser

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
