Specifications
Media Specifications
6/15/09 S4M User Guide 13290L-004 Rev. A
Media Specifications
Media Specifications
Label length Minimum (Tear-Off) 0.7 in. 17.8 mm
Minimum (Peel-Off) 0.5 in. 12.7 mm
Maximum 39 in. 991 mm
Label width Minimum 0.75 in. 19 mm
Maximum 4.5 in. 114 mm
Total thickness
(includes liner, if any)
Minimum 0.003 in. 0.076 mm
Maximum 0.010 in. 0.25 mm
Maximum roll outside
diameter
3-in. (76 mm) core 8 in. 203 mm
1-in. (25 mm) core 6 in. 152 mm
Inter-label gap Minimum 0.079 in. 2 mm
Preferred 0.118 in. 3 mm
Maximum 0.157 in. 4 mm
Ticket/tag notch size (width x length) 0.25 in. × 0.12 in. 6 mm × 3 mm
Hole diameter 0.125 in. 3 mm
Notch or hole position
(Centered from inner
media edge)
Minimum 0.15 in. 3.8 mm
Maximum 2.25 in. 57 mm
Density, in Optical Density Units (ODU) (black mark) > 1.0 ODU
Maximum media density <
0.5 ODU
Transmissive Sensor Fixed 7/16 in. (11 mm) from inside edge

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
