ZXR102900ESeriesCommandReference
ParameterDescription
cos<0-7>
Thisruleisonlyvalidforthecos-speciedmessages.Ignorethis
ruleforothermessages.Therangeofcosis0to7.
<vlan-id>
ThisruleisonlyvalidformessageswiththespeciedVLANID.
Ignorethisruleforothermessages.TheruleofVLANIDis1
to4094.
<vlan-mask>OptionalVLANmask.Thedefaultvalueis0xfff.
<source-mac>SourceMACaddressofthetransmittedpacket.
<smac-mask>SourceMACmask.
any(third)
TheanykeywordisusedastheabbreviationofsourceMAC
address00.00.00.00.00.00andmask00.00.00.00.00.00.
<dest-mac>DestinationMACaddressofthetransmittedpacket.
<dmac-mask>DestinationMACmask.
any(fourth)
Theanykeywordisusedastheabbreviationofthedestination
MACaddress00.00.00.00.00.00andmask00.00.00.00.00.00.
Guidelines
Ip-protocolrulecanmatchIPv4–speciedprotocoleld,source-speciedIP ,anysource
IP ,destination-speciedIP,anydestinationIP,DSCPeld,IPfragmenteld,coseld,
VLANeld,source-speciedMAC,anysourceMAC,destination-speciedMACandany
destinationMAC.
4.13.67egress-aclhybridruletype-ip
Purpose
ThiscommandsetstherulethatthehybridegressACLmatchesIPv4packets.
CommandMode
HybridegressACLcongurationmode
Syntax
rule<1-500>{permit|deny}ip{<source-ipaddr><sip-mask>|any}{<destination-ipaddr><dip-m
ask>|any}[dscp<0-63>][fragment][cos<0-7>][<vlan-id>[<vlan-mask>]][<source-mac><smac
-mask>|any][<dest-mac><dmac-mask>|any]
ParameterDescription
ParameterDescription
<1-500>Rulenumber.
4-278
SJ-20130731155059-003|2013-11-27(R1.0)ZTEProprietaryandCondential
