ABB 650 series Engineering Manual

Section 5 Protection and control engineering
5.1 Creating an application configuration with ACT
5.1.1 Overview
ACT is used to create the application configuration for an IED. The application
configuration is built up with function blocks.
Function blocks are dedicated for different functionality, for example:
• Preprocessing blocks
• Control related functions
• Protection related functions
• Monitoring functions
• Communication
For detailed information about function blocks see the technical
manual and the application manual.
Some function blocks are mapped as logical nodes according to the IEC 61850
standard. See the IEC 61850 communication protocol manual for detailed
information. Other function blocks are not mapped as logical nodes, for example:
• Logical gates
• Timers
The basic general features of the Application configuration tool ACT:
• Organization of an application configuration
• Organize an application configuration into a number of logical parts
(MainApplication).
• Organize a MainApplication over a number of pages.
• Features to program an application configuration:
• Insert function blocks, make connections and create variables.
• Include the hardware IO channels directly in the application configuration.
• Set function blocks and signal visibility to SMT and PST.
1MRK 511 284-UEN A Section 5
Protection and control engineering
650 series 49
Engineering manual
