Category IEC Symbol Name Symbol
Type
IEC Symbol
Definitions
ANSI Y32.2/
IEEE 315
Symbol
Definitions
Function Block
Type
Texts Indication button, 00 =
Middle position
31 VSGGIO
Indication button, 01 =
Open
Indication button, 10 =
Closed
Indication button, 11 =
Undefined
Texts Dynamic text, 32 36 SLGGIO
Texts Selector switch, 00 =
Middle position
37 SLGGIO
Selector switch, 01 =
Open
Selector switch, 10 =
Closed
Selector switch, 11 =
Undefined
Texts Selector switch indicate,
00 = Middle position
38 SLGGIO
Selector switch indicate,
01 = Open
Selector switch indicate,
10 = Closed
Selector switch indicate,
11 = Undefined
Others Resistor 39
Others Star point 40
Others Field winding 41
6.2.3 Bay configuration engineering
A page with a single line diagram and measurements contains active living objects.
The object values are updated by the IED periodically (measurement) or in case of an
event. Once the symbols are placed on the HMI page they must be linked to the
corresponding function block in the application configuration, which protects or
controls the object that the symbol on the HMI page represents.
1MRK 511 284-UEN A Section 6
Local HMI engineering
650 series 83
Engineering manual
