ABB 650 series Engineering Manual

IEC08000364.vsd
LN
GOOSE
Send
C
o
m
m
u
n
i
c
a
t
i
o
n
h
a
n
d
l
e
r
I
E
C
6
1
8
5
0
p
r
o
t
o
c
o
l
Commands
Event
handler
Event
queue
C
o
m
m
a
n
d
/
I
N
/
O
U
T
i
n
t
e
r
f
a
c
e
A
F
p
a
r
t
GOOSE
Send
GOOSE
Receive
FBs
with
monitoring
and
commands
FBs
with
monitoring
only
G
O
O
S
E
i
n
t
e
r
f
.
FB
AFL
LN
part
FB
AFL
LN
part
FB
AFL
LN
part
LN
GOOSE
Send
FBs
GOOSE
Receive
FBs
GOOSE
Receive
IEC08000364 V1 EN
Figure 61: IEC 61850: Communication interface principle
IEC 61850 has as a concept for the identification of all signals for communication that
belong to a function by a logical node as a placeholder. All signal information in
command and monitoring direction, which belongs to a function, is available within
the logical node.
Whenever a function block is instantiated in ACT, PCM600 automatically generates
the corresponding logical node data. In
Figure 61 this is shown by two parts per
function block. The upper part is the visible function block in ACT and the lower part
is the logical node data for the function block.
7.1.2.1 GOOSE data exchange
The IEC 61850 protocol supports a method to directly exchange data between two or
more IEDs. This method is described in the IEC 61850–7–2 clause 15. The concept is
based on sending a multicast over the Ethernet. Whoever needs the information
detects the telegram by its source address and will read the telegram and deals with it.
The telegrams are multicast sent and not acknowledged by the receiver.
Section 7 1MRK 511 284-UEN A
IEC 61850 communication engineering
90 650 series
Engineering manual
