ABB 650 series Engineering Manual

IEC08000401.vsd
= Steady = FlashIllumination =>
Man-
Reset
S1
S2
S3
S4
tMax
tRestart
S1LED
S2LED
S3LED
S4LED
Auto-
Reset
IEC08000401 V1 EN
Figure 53: LHMI LED operation mode LatchedReset-S / 2
6.2 Single-line diagram engineering
Phase angles are shown as radians in the single line diagram (GDE
measurand) symbols but in degrees in other views on the LHMI.
6.2.1 Concept description to present and generate diagrams in
graphical display editor
Additional concept information to use GDE, see
Figure 54:
• Different GDE windows
• HMI display raster layouts
• Drawing lines (doing a Link)
1MRK 511 284-UEN A Section 6
Local HMI engineering
650 series 73
Engineering manual
