The IED name in an exported .icd file is always named
TEMPLATE.
• Capability description of the IED in logical nodes and their data. No
information about communication configuration, for example, is included.
• An IED is already extended by default data sets. They are predefined by
ABB. Changes or additional data sets, for example, have to be done with the
IET600 station configuration tool.
• SCD = Station Configuration Description
• Complete configuration description of all IEDs in a station and the full
engineering of process signals and communication structure is included.
This includes all needed data sets and all control blocks.
• CID = Configured IED Description
• The CID file contains the information needed to configure just one specific
IED.
The uploading of IEC 61850 communication configuration is not
supported when reading a configuration from an online IED.
7.2 IEC 61850 engineering procedure
7.2.1 IEC 61850 protocol references and pre-conditions
To engineer the IEC 61850 protocol interface for the IED, the following additional
manuals or knowledge of their contents is required.
• Knowledge of the IEC 61850 engineering process as described in the IEC 61850
standard.
• The Technical Manual describes function blocks defined as logical nodes.
• The IEC 61850 Communication Protocol Manual.
• The IEC 61850 conformance documents for the IED to be engineered.
7.2.2 Sequence for engineering of IEC 61850 protocol
The IEC 61850 standard defines the complete part needed for information
communication in a substation. This can be split into the following parts:
• Description of the substation part including the used logical nodes
• Description of the IEDs with their logical nodes
• Description of the communication network
• Description of the engineering process
Section 7 1MRK 511 284-UEN A
IEC 61850 communication engineering
92 650 series
Engineering manual
