System description Advant Controller 31.
Connection to the CS31 bus
Data Value
Connections X1/B2, X1/B1
CS31 bus type 05 (analog input/output)
Termination resistor Not available (must be provided externally if
needed)
Mechanical data
Data Value
Width x height x depth Replacement device: 120 x 140 x approx. 80
mm
Existing device: 120 x 140 x 85 mm
Weight Replacement device: 362 g
Existing device: 450 g
Dimensions for mounting See assembly instructions 07AC91-AD2
(3ADR020085M0401)
Mounting information
The dimensions for the assembly holes are the same for the replacement
device and the existing device.
To assemble or disassemble the replacement device, grab the device at the housing and not
directly at the S500 module.
Ordering data
Order No. Scope of delivery
1SAP 800 100 R0010 Analog input/output module 07AC91-AD2
1x 2-pole terminal block (3.81 mm grid space)
1x 3-pole terminal block (5.08 mm grid space)
1x 5-pole terminal block (5.08 mm grid space)
4x 8-pole terminal blocks (3.81 mm grid
space)
Replacement devices: I/O modules > Replacement device 07AC91-AD2
