Table 4: AC voltage tests
Data Voltage Duration
24 V circuits (supply, 24 V inputs/outputs), when electri-
cally isolated from other circuitry
350 VAC 60 s
CS31 interface from other circuitry 350 VAC 60 s
Ethernet 350 VAC 60 s
ARCNET 350 VAC 60 s
COM interfaces, electrically isolated 350 VAC 60 s
Enabling input, electrically isolated 350 VAC 60 s
1.3.1.4 Power Supply Units
For the supply of devices, use power supply units according to PELV specification.
1.3.1.5 Electromagnetic compatibility
Table 5: Immunity
Data Value
Immunity against electrostatic discharge
(ESD)
According to EN 61000-4-2, zone B, criterion
B
-> Interference voltage with air discharge 8 kV
-> Interference voltage with contact discharge 4 kV
ESD with communication connectors Ensure that any electrostatic charge is dis-
charged prior to contact with the communica-
tion connectors (e.g. by touching an earthed
metal object). Otherwise malfunctions may
occur.
ESD module carrier connectors Do not touch the plug connecting the module
carrier on the bottom side of the device.
ESD external coupler interface Do not touch the plug to the flat ribbon cable.
Immunity against the influence of radiated
interference (CW radiated)
According to EN 61000-4-3, zone B, criterion
A
-> Test field strength 10 V/m (except ITU transmission bands 87…
108 MHz, 174…230 MHz and 470…790 MHz
-> 3 V/m)
-> Maximum temporary deviation during irradi-
ation
Analog current output signals max. 1.5 %.
Devices affected:
07AC91-AD, 07AC91-AD2,
07KT94-ARC-AD, 07KT98-ARC-AD,
07KT98-ARC-DP-AD, 07KT98-ARC-ETH-AD,
07KT98-ETH-DP-AD, 07KT98-ARC-ETH-DP-
AD
Immunity against transient interference vol-
tages (burst)
According to EN 61000-4-4, zone B, criterion
B
-> Voltage supply 2 kV
-> Enabling input 2 kV
AC31 Adapters
System data and CS31 bus system data > System data of the AC31 adapters
2018/09/243ADR010122, 8, en_US6
