ACS 600 MultiDrive A-1
ACS 600 MultiDrive – Technical Data
Abbreviations
The abbreviations used in the following supply and drive section rating
tables are explained below.
Note 1: Drive section output currents are valid when output frequency is above 10 Hz.
Note 2: The ratings given correspond to voltage U
N
and fan supply voltage 230 V or
115 V.
Note 3: The limiting factor for P
G
in thyristor supply sections with autotransformer is
either the autotransformer or the generator bridge current depending on the
configuration of the supply section.
Supply Section Drive Section
I
1N
Total rms input current (continuous a.c.
current)
I
2N
Rated rms a.c. output current (= maximum
continuous output current)
Duty Cycle (10 s / 60 s) 200 % Duty Cycle (10 s / 60 s)
I
DCbase
Maximum base current with I
DCmax
. I
DCbase
is
60 % of I
DC
.
I
2base
Maximum base current with I
2max
. I
2base
is the
nominal heavy duty output current.
I
DCmax
Short term rms overload d.c. current (allowed for
10 seconds every 60 seconds)
I
2max
Short term rms a.c. overload current (allowed for
10 seconds every 60 seconds) i.e. maximum
output current
Duty Cycle (1 min / 5 min) 150 % Duty Cycle (1 min / 5 min)
I
DCbase
Maximum base current with I
DCmax
. I
DCbase
is
60 % of I
DC
.
I
2base
Maximum base current with I
2max
I
DCmax
Short term rms overload d.c. current (allowed for
one minute every 5 minutes).
I
2max
Short term rms a.c. overload current (allowed for
one minute every 5 minutes)
I
DC
Continuous d.c. current
S
N
Rated apparent output power of the supply
section
S
N
Rated apparent output power of the drive
section
P
N
Nominal output power (continuous active
power)
P
N
Typical motor power. The power ratings in kW
apply to most IEC 34 motors.
P
G
Regenerative braking power to mains
P
loss
Power loss
U
N
Nominal mains voltage U
N
Nominal mains voltage
10 s
50 s
I
DCmax
I
DCbase
10 s
50 s
I
2max
I
2base
1 min
4 min
I
DCmax
I
DCbase
1 min
4 min
I
2max
I
2base
