ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-17
Ratings The table below shows the nominal ratings for the dynamic braking
sections.
*
The ACA 621 braking sections are not equipped with the braking resistors. They must
be installed by the user.
Section Chopper Resistor P
br.max
(kW)
R
(ohm)
I
max
(A)
P
cont.
(kW)
Duty Cycle
(1min/5min)
Duty Cycle
(10s/60s)
P
br.
(kW)
I
rms
(A)
P
br.
(kW)
I
rms
(A)
Braking sections (380...415 V Range,U
N
= 400 V)
ACA 621-0210-3 NBRA658 * 230 1.7 384 70 230 355 230 355
ACA 621-0320-3 NBRA659 * 353 1.2 545 96 303 468 353 545
ACA 621-0640-3 2 x NBRA659 * 706 1.2 545 192 606 468 706 545
ACA 621-0960-3 3 x NBRA659 * 1058 1.2 545 288 909 468 1059 545
ACA 621-1280-3 4 x NBRA659 * 1411 1.2 545 384 1212 468 1412 545
ACA 621-1600-3 5 x NBRA659 * 1764 1.2 545 480 1515 468 1765 545
ACA 621-1920-3 6 x NBRA659 * 2117 1.2 545 576 1818 468 2118 545
ACA 622-0210-3 NBRA658 2 x SAFUR210F575 230 1.7 384 42 130 200 224 345
ACA 622-0320-3 NBRA659 2 x SAFUR180F460 353 1.2 545 54 167 257 287 444
ACA 622-0640-3 2 x NBRA659 2 x (2 x SAFUR180F460) 706 1.2 545 108 333 257 575 444
ACA 622-0960-3 3 x NBRA659 3 x (2 x SAFUR180F460) 1058 1.2 545 162 500 257 862 444
ACA 622-1280-3 4 x NBRA659 4 x (2 x SAFUR180F460) 1411 1.2 545 216 667 257 1150 444
ACA 622-1600-3 5 x NBRA659 5 x (2 x SAFUR180F460) 1764 1.2 545 270 833 257 1437 444
ACA 622-1920-3 6 x NBRA659 6 x (2 x SAFUR180F460) 2117 1.2 545 324 1000 257 1724 444
Braking sections (380...500 V Range,U
N
= 500 V)
ACA 621-0260-5 NBRA658 * 268 2.15 380 81 268 331 268 331
ACA 621-0400-5 NBRA659 * 403 1.43 571 109 317 391 403 498
ACA 621-0800-5 2 x NBRA659 * 806 1.43 571 218 634 391 806 498
ACA 621-1200-5 3 x NBRA659 * 1208 1.43 571 327 951 391 1209 498
ACA 621-1600-5 4 x NBRA659 * 1611 1.43 571 436 1268 391 1612 498
ACA 621-2000-5 5 x NBRA659 * 2014 1.43 571 545 1585 391 2015 498
ACA 621-2400-5 6 x NBRA659 * 2417 1.43 571 654 1902 391 2418 498
ACA 622-0260-5 NBRA658 2 x SAFUR125F500 268 2.00 408 36 111 137 192 237
ACA 622-0400-5 NBRA659 2 x SAFUR200F500 403 1.35 605 54 167 206 287 355
ACA 622-0800-5 2 x NBRA659 2 x (2 x SAFUR200F500) 806 1.35 605 108 333 206 575 355
ACA 622-1200-5 3 x NBRA659 3 x (2 x SAFUR200F500) 1208 1.35 605 162 500 206 862 355
ACA 622-1600-5 4 x NBRA659 4 x (2 x SAFUR200F500) 1611 1.35 605 216 667 206 1150 355
ACA 622-2000-5 5 x NBRA659 5 x (2 x SAFUR200F500) 2014 1.35 605 270 833 206 1437 355
ACA 622-2400-5 6 x NBRA659 6 x (2 x SAFUR200F500) 2417 1.35 605 324 1000 206 1724 355
Braking sections (525...690 V Range,U
N
= 690 V
ACA 621-0400-6 NBRA669 * 404 2.72 414 119 298 267 404 361
ACA 621-0800-6 2 x NBRA669 * 807 2.72 414 238 596 267 808 361
ACA 621-1200-6 3 x NBRA669 * 1211 2.72 414 357 894 267 1212 361
ACA 621-1600-6 4 x NBRA669 * 1615 2.72 414 476 1192 267 1616 361
ACA 621-2000-6 5 x NBRA669 * 2019 2.72 414 595 1490 267 2020 361
ACA 621-2400-6 6 x NBRA669 * 2422 2.72 414 714 1788 267 2424 361
ACA 622-0400-6 NBRA669 2 x SAFUR200F500 404 1.35 835 54 167 149 287 257
ACA 622-0800-6 2 x NBRA669 2 x (2 x SAFUR200F500) 807 1.35 835 108 333 149 287 257
ACA 622-1200-6 3 x NBRA669 3 x (2 x SAFUR200F500) 1211 1.35 835 162 500 149 575 257
ACA 622-1600-6 4 x NBRA669 4 x (2 x SAFUR200F500) 1615 1.35 835 216 667 149 862 257
ACA 622-2000-6 5 x NBRA669 5 x (2 x SAFUR200F500) 2019 1.35 835 270 833 149 1150 257
ACA 622-2400-6 6 x NBRA669 6 x (2 x SAFUR200F500) 2422 1.35 835 324 2000 149 1724 257
PDM code 00017952-C
