ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-25
Branch Fuses Frame B4 to B5 diode and thyristor supply modules employ internal
branch fuses instead of input or output fuses. The table lists the
applicable Bussmann types.
Branch Fuses for Frame B4 and B5 Supply Modules
Supply Module
Type
U
N
(V)
I
N
(A)
Pre-arching Integral
(A
2
s)
Type Size
ACN 654 0855 5
ACN 664 0855 5
ACN 684 0855 5
660 900 100000 170M6163 3/110
ACN 654 1405 5
ACN 664 1405 5
ACN 684 1405 5
660 1500 460000 170M6168 3/110
ACN 654 2120 5
ACN 664 2120 5
ACN 684 2120 5
ACN 654 2600 5
ACN 664 2600 5
ACN 684 2600 5
ACN 654 0855 6
ACN 664 0855 6
ACN 684 0855 6
1250 630 83500 170M6144 3/110
ACN 654 1405 6
ACN 664 1405 6
ACN 684 1405 6
1250 1100 575000 170M6149 3/110
ACN 654 2600 6
ACN 664 2600 6
ACN 684 2600 6
ACN 654 3600 6
ACN 664 3600 6
ACN 684 3600 6
1110 1400 1250000 170M6151 3/110
ACN 654 1685 8
ACN 664 1685 8
1250 1100 575000 170M6149 3/110
ACN 654 3100 8
ACN 664 3100 8
ACN 654 3520 8
ACN 664 3520 8
1110 1400 1250000 170M6151 3/110
ACN 654 4310 8
ACN 664 4310 8
PDM code 00004021-B
