ACS 600 MultiDrive – Technical Data
A-12 ACS 600 MultiDrive
Drive Section Tables
The following tables specify the ratings for the drive sections.
Notes The notes concerning the following drive section tables are listed
below.
P
loss
P
loss
is the heat loss of a unit with basic options.
Noise Level Noise level applies to echoless room.
Height The height of the cabinet for IP 21/22/42 classification is 2065 mm up
to frame type R7i. The height of frame type R8i and above is 2130 mm.
Cabinet height is 2072 mm for IP 54R classification.
Depth The depth of the cabinet is 600 mm.
Width and Weight
Note Description Weight
kg
1 200 mm is added with the top exit 40
2 400 mm is added with the top exit 110
3 600 mm is added with the top exit 160
4 800 mm is added with the top exit and/or common motor
connection terminals
230
5 600 mm is added with the top exit and/or common motor
connection terminals
190
6 The width is 400 mm with no options and 600 mm when
optional devices are included. 600 mm is added when more
than one inverter unit is used in the drive section.
7 200 mm wide joining cabinet is added (max. transportation
length is 4000 mm)
40
PDM code 00004863-D
